Admin Guide Overview

This Admin Guide provides information about how to configure your 47Lining Enterprise PaaS - Preview Deployment, and what underlying AWS resources you can expect your Preview Deployment to create on your behalf in your AWS account. The Admin Guide describes AWS services architecture, user setup and authorization, and how to ingest your own data in the following pages.

AWS Service Architecture

AWS Service Architecture for Preview Deployment

Your 47Lining Enterprise PaaS - Preview Deployment includes a Preview Deployment instance of the most recent development release of the OSDU™ Data Platform and uses the following prerequisite and underlying AWS Services.

Preview Deployment Architecture

AWS Services

Infrastructure

Your 47Lining Enterprise PaaS - Preview Deployment of the OSDU Data Platform is deployed into a single AWS Account. All AWS services used will be launched within and billed to that account. The OSDU Forum provides open source code that is then deployed to AWS and linked to cloud-provider-specific prerequisite services through a Service Provider Interface (SPI). In some cases the infrastructure is dedicated and persistent and in other cases it is serverless or ephemeral.

Data

When you load the OSDU Data Platform with data, the data platform persists your data using Amazon S3 and Amazon DynamoDB. You use the OSDU Data Platform APIs to load, search for, and retrieve data. Apart from the OSDU Data Platform APIs, neither you nor other users should typically have direct access to the data or to the underlying AWS services used to manage and store data that has been loaded to the data platform.

An administrator of the AWS account where your Preview Deployment resides may provide access policies that enable access to these underlying AWS services and resources, but you should use the OSDU Data Platform APIs to interact with your data. Such direct access may sometimes be useful when attempting to diagnose unexpected behavior or other issues to root cause.

Security

In order to provide secure access to the OSDU Data Platform, the entitlements service is used for user and group management. Using this service, users can be granted access to the API endpoints, allowing for certain actions to be undertaken by users of different types. The entitlements service can also be used to grant access to datasets based on a prescribed set of parameters such as geographic region.

Cost

47Lining provides your Preview Deployment of the latest development release of the OSDU Data Platform as a metered, consumption-based SaaS service. As described in Pricing, we make your Preview Deployment available to you for less than a dollar per month.

This means that you can easily access and use OSDU Data Platform services at minimal cost beyond the cost of the underlying AWS services. Charges for those AWS services will be included on your monthly AWS invoice. A separate item for the minimal monthly charges resulting from your AWS Marketplace subscription to the Preview Deployment will also appear on your monthly AWS invoice.

AWS Services Used within the Preview Deployment

All Services

Deployed by AWS CodePipeline in Amazon VPC with logging to Amazon CloudWatch
Services are behind Amazon CloudFront and an AWS Application Load Balancer
Deployment uses AWS Systems Manager Parameter Store to store and securely access parameters
